FR Compact 46

Products

FR Compact 46

Full capability performance in compact

COMPACT is a convection oven equipped with forced air circulation and a rotating rack.
Offering excellent baking performance in minimal space.
Its versatility makes it ideal for a wide variety of bread and pastry products, both in small and medium-scale production.

Thanks to the balanced airflow and rotating rack, COMPACT ensures even and consistent baking, delivering outstanding volume, softness, and overall product quality.

Key Forniture:
- Forced air convection system with balanced airflow for uniform heat distribution.
- Removable rotating rack with a capacity of 15 trays (cm.40x60).
- Available in electric version with high-performance armored heating elements, or with a gas/diesel burner.
- Full stainless steel construction for maximum durability and hygiene.
- Double-glass door for optimal thermal insulation and clear visibility during baking.

Steam Generation System:
- Built-in removable steamer inside the baking chamber, activated by a programmable timer.
- Manual or automatic steam exhaust valve.
- Excellent heat and steam distribution, even during continuous production cycles.

Ideal For:
- Pastry shops.
- Pastry shops that also produce bread.
- Shops where the space is particularly limited.
- Small pastry and bakery shops that don’t want to give up the convenience of working with pull-out trolleys.

COMPACT is the synthesis of compact design and outstanding results.
A baking experience that satisfies.

ico_prodotto_01
Features

• Even heat distribution throughout the baking chamber ensures uniform results.
• Electric voltage: 400/50-60/3 -220/50-60/3 -220/1 (GAS).
• Electric voltage: 208/60/3 -110/1 (GAS).
• Multiple versions: mechanical or LCD programmable panel

ico_prodotto_01
Specifications

• Door passage assembled
   FR COMPACT 46E: mm.1121x2255, inch 44.15x88.80.
   FR COMPACT 46Gas: mm.981x2145, inch 44.15x84.45.
• Maximum rotation diagonal: mm.720, inch 28.35.
• Water connection: inlet 1/2’’, outlet 1’’.
• Steam exhaust outlet: 150 mm, in 6".
• Smoke exhaust outlet: 120 mm, 5".
• 2-years guaranteed

MODEL TRAY DISTANCE BAKING SURFACE  DIMENSIONS POWER WEIGHT
  CM NR MM MQ MM - W x L x H + H1 KW KW KCAL KG
FR COMPACT E46 ELECTRIC 40x60 15 97 3.60 980 x 1190 x 2020 + 330 1 23.5   550
FR COMPACT G46 BURNER 40x60 15 97 3.60 980 x 1190 x 2020 + 330 1   29.000 650
