• Even heat distribution throughout the baking chamber ensures uniform results.
• Electric voltage: 400/50-60/3 -220/50-60/3 -220/1 (GAS).
• Electric voltage: 208/60/3 -110/1 (GAS).
• Multiple versions: mechanical or LCD programmable panel.
SINGLE RACK OVEN
FR BABY is a next-generation convection oven designed to deliver high performance in environments with limited height, without compromising on quality or capacity.
Thanks to forced air circulation and a rotating rack system, it ensures fast, even, and consistent baking .
Ideal for a wide variety of small to medium-sized bakery and pastry products.
Key Forniture:
- Forced air convection system with balanced airflow for uniform heat distribution.
- Removable rotating rack with a capacity of 12 trays (18x26 inches).
- Available in electric version with high-performance armored heating elements, or with a gas/diesel burner.
- Full stainless steel construction for maximum durability and hygiene.
- Double-glass door for optimal thermal insulation and clear visibility during baking.
Steam Generation System:
- Built-in removable steamer inside the baking chamber, activated by a programmable timer.
- Manual steam exhaust valve.
- Excellent heat and steam distribution, even during continuous production cycles.
Ideal For:
- Pastry shops
- Small bakeries
- Café kitchens
- Bakery schools
"The FR BABY delivers full-size results in half the space - we bake 120 big croissants per batch with perfect consistency."
- Sofia R., Patisserie Owner
• Even heat distribution throughout the baking chamber ensures uniform results.
• Electric voltage: 400/50-60/3 -220/50-60/3 -220/1 (GAS).
• Electric voltage: 208/60/3 -110/1 (GAS).
• Multiple versions: mechanical or LCD programmable panel.
• Door passage assembled
FR BABY 57: mm.1121x1593, inch 44.15x62.75.
• Maximum rotation diagonal:
FR BABY 57: mm. 885, inch 34.85.
• Water connection: inlet 1/2’’, outlet 1’’.
• Steam exhaust outlet: 120 mm, in 5".
• Smoke exhaust outlet: 120 mm, 5".
• 2-years guaranteed
MODEL | TRAY | DISTANCE | BAKING | DIMENSIONS | POWER | WEIGHT | |||
---|---|---|---|---|---|---|---|---|---|
INCH | NR | INCH | FT2 | INCH - W x L x H + H1 | KW | KW | KCAL | LBs | |
FR BABY E57 | 18 x 26 | 12 | 3.15 | 45 | 44 x 65 x 58 + 3.5 | 1 | 17 | 1100 | |
FR BABY 57 | 18 x 26 | 12 | 3.15 | 45 | 44 x 65 x 58 + 3.5 | 1 | 23.000 | 1100 |
MODEL | TRAY | DISTANCE | BAKING | DIMENSIONS | POWER | WEIGHT | |||
---|---|---|---|---|---|---|---|---|---|
CM | NR | MM | MQ | MM - W x L x H + H1 | KW | KW | KCAL | KG | |
FR BABY E57 | 50 x 70 | 12 | 80 | 4.2 | 1120 x 1640 x 1470 + 90 | 1 | 17 | 500 | |
FR BABY 57 | 50 x 70 | 12 | 80 | 4.2 | 1120 x 1640 x 1470 + 90 | 1 | 23.000 | 500 |
